PE3C5880 CAD Drawing
Plenum 7/16 DIN Male to SMA Female Low PIM Cable
Using SPP-250-LLPL Coax , LF Solder

CN2379

7/16 DIN MALE SIZE A

.83 [21.0] FLATS 6'' FROM CABLE END 1 PLACE. 1.26 [32.0] HEX FLATS TYP. 2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME. SCALE N/A

SERIAL # PIM LEVEL -zzzdBc PIM LABEL NOTES: 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL. 3. DIMENSIONS ARE IN INCHES [mm]. 12/26/18 CAD FILE

LENGTH MEASURED FROM END TO END PE LABEL - LABEL CENTERED 84'' OR LESS. - GREATER THAN 84'' LABEL 2 PLACES 12'' FROM CABLE END. PE3C5880 CAGE CODE 53919

www.PASTERNACK.com PART # DWG TITLE

R
SPP-250-LLPL THE ENGINEER'S RF SOURCE
P.O. Box 16759 | Irvine | CA | 92623
Pasternack Enterprises, Inc.

HEAT SHRINK PROTECTOR (2X) Pasternack does not make Phone: (949) 261-1920 | Fax: (949) 261-7451 Website: www.pasternack.com | E-Mail: sales@pasternack.com

.28 [7.0] FLATS SMA FEMALE STANDARD TOLERANCES *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES

.XXX ±0.005
.XX ±0.01
.X ±0.2

any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation. -

PE3C5880 REV 1.0 6
