Page 2008 - 1.0/2.3 to BMA RF Cable Assembly Datasheets

Slide-On BMA Plug Bulkhead to Slide-On BMA Jack
Bulkhead Cable Using PE-SR405FLJ Coax

RF Cable Assemblies Technical Data Sheet PE3C4851

Typical Performance Data
2 HOLE FLANGE CUTOUT

2X
#2-56 UNC-2B
+.000
.378 -.002
BMA JACK BULKHEAD CUTOUT 9.60 0.00
-0.05
.320 +.001
-.000
+0.03
8.13 0.00 .559±.004
14.20±0.10

MOUNTING HOLE
MOUNTING HOLE

BMA PLUG BULKHEAD CUTOUT
.243
.242
6.17
6.15

MOUNTING HOLE

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: Slide-On BMA Plug Bulkhead to Slide-On BMA Jack Bulkhead Cable Using PE-SR405FLJ
.243
.242
Coax PE3C4851 PANEL CUTOUT Pasternack does not make -
6.17
6.15
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.
.500±.003
12.70±0.07
.450 +.001
-.000
11.43 +0.03
0.00
PE3C4851 REV 1.2 4
MOUNTING HOLE

.341 +.002 .317±.001
-.000
8.66 +0.05 8.05±0.02
0.00

PANEL DRILLING
