Page 2104 - 1.0/2.3 to BMA RF Cable Assembly Datasheets

Slide-On BMA Plug Bulkhead to N Male
Cable Using LMR-100 Coax

RF Cable Assemblies Technical Data Sheet PE3C4931

Typical Performance Data
2X
#2-56 UNC-2B
.378 +.000
-.002
0.00
9.60 -0.05

.559±.004
14.20±0.10
.243
.242
6.17
6.15

MOUNTING HOLE

MOUNTING HOLE

.320 +.001
-.000
+0.03
8.13 0.00

MOUNTING HOLE

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
.500
inventory and certifications: Slide-On BMA Plug Bulkhead to N Male Cable Using LMR-100 Coax PE3C4931
12.70
.450 -
11.43 Pasternack does not make
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.

.341 A A .317
8.66 8.05
PE3C4931 REV 1.1 4

PANEL DRILLING

SECTION A-A
SCALE 3 : 1
