N Male Right Angle to TNC Male Right Angle
Low Loss Cable Using PE-P160LL Coax

RF Cable Assemblies Technical Data Sheet PE3C5284

Typical Performance Data
Attenuation Characteristics for Pasternack's Family
of Low Loss High Performance Microwave Cables
50

45
40
PE-P160LL
35
30 PE-P142LL
Attenuation (dB/100ft) 25

20
PE-P300LL
15

10
5
0
0 2 4 6 8 10 12 14 16 18 20
Frequency
(GHz)

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including
price, inventory and certifications: N Male Right Angle to TNC Male Right Angle Low Loss Cable Using PE-P160LL Coax
