PE3M0242 CAD Drawing
Temperature Conditioned TNC Male to N Male Right Angle
Low Loss Cable Using PE-P300LL Coax

APPROVED D.BIRCH 1.15±.01 29.1±0.3 RP IS THE PROPERTY OF PASTERNACK CORPORATION. ALL RIGHTS RESERVED. 1 N/A REV A

THE INFORMATION AND DESIGN IN THIS DOCUMENT SHEET OF 1
DATE 02/08/19 SCALE
CONTACT PE45225 N MALE RIGHT ANGLE PE3M0242

REVISIONS PART NUMBER

DESCRIPTION INITIAL RELEASE 9/16 FLATS P2 CAGE 53919 3/4 HEX Pasternack Enterprises, Inc. P.O.Box 16759, Irvine, CA 92623. Phone: 1.949.261.1920 │ 1.866.727.8376 Fax: 1.949.261.7451 www.pasternack.com │ e-mail: sales@pasternack.com DRAWN BY K.DANG

REV. A CAGE SIZE 53919 A

UNLESS OTHERWISE SPECIFIED LEADING DIMENSIONS ARE INCHES DIMENSIONS IN [ ] ARE MILLIMETERS TOLERANCES: .2 [5.08] .X=± .01 [ .25 ] .XX=± .005 [ .13 ] .XXX=± ALL DIMENSIONS SHOWN ARE FOR REFERENCE ONLY. THIRD-ANGLE PROJECTION
2 FRACTIONS ± 1/32 ANGLES ± 1°

LENGTH MEASURED FROM RF. PLANE TO CONTACT PASTERNACK PE3M0242-XXX SN XXXX D/C WWYY

PE-P300LL

2 THESE COMMODITIES, TECHNOLOGY OR SOFTWARE WERE EXPORTED FROM THE UNITED STATES IN ACCORDANCE WITH THE EXPORT ADMINISTRATION REGULATIONS. DIVERSION CONTRARY TO U.S. LAW PROHIBITED.
9/16 FLATS ALL BLACK HEAT SHRINK WITH WHITE MARKINGS. TOP LAYER: SUMITUBE W3B2 (4X) - SIZE 24/6.

9/16 HEX PE44810 TNC MALE
P1 BOTTOM LAYER: M23053/4-304-0.

.030
0.76
REF
Pasternack does not make
RP
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation. -
NOTES:
1.
2.
T-Rev.A
PE3M0242 REV 1.2 7
