BNC Tee Adapter Male-Female-Female
RF Adapters Technical Data Sheet PE9174
.
Description Connector 1 Connector 2
Type BNC Male BNC Female
Polarity Standard Standard
.
Material Specifications
Connector 1 Connector 2
Description Material Plating Material Plating
Type BNC Male BNC Female
Contact Phosphor Bronze Gold Phosphor Bronze Gold
Insulation PTFE PTFE
Outer Conductor Brass Nickel
100 µ-in minimum
Body Brass Nickel
100 µ-in minimum
Coupling Nut Brass Nickel
100 µ-in minimum
. .
Environmental Specifications
Temperature
Operating Range -65 to +165 deg C
.
Compliance Certifications (see product page for current document)
Plotted and Other Data
Notes:
Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: BNC Tee Adapter Male-Female-Female PE9174
PE9174 REV 1.4 2
