30 dB With 5 Bit Programmable TTL Controlled
Attenuator, 2.92mm Female To 2.92mm Female,
1 dB Steps From 100 MHz To 40 GHz
TECHNICAL DATA SHEET PE70A5002
Performance Data
+25°C Attenuation vs. Frequency Plot
ATTENUATION VS FREQUENCY
0
5
ATTENUATION (dB) 15
10
20
25
30
35
0 5 10 15 20 25 30 35 40
FREQUENCY (GHz)
-40°C Attenuation vs. Frequency Plot
0 ATTENUATION VS FREQUENCY
5
ATTENUATION (dB) 15
10
20
25
30
35
0 5 10 15 20 25 30 35 40
FREQUENCY (GHz)
+85°C Attenuation vs. Frequency Plot
ATTENUATION VS FREQUENCY
0
5
ATTENUATION (dB) 15
10
20
25
30
35
0 5 10 15 20 25 30 35 40
FREQUENCY (GHz)
