PE70A5013 CAD Drawing
Bench-Top 95 dB Programmable TTL Controlled Attenuator, SMA
Female to SMA Female, 1 dB Steps From 200 MHz to 6 GHz

CN_1408

FOUNCTION CHASSIS GROUND RECEIVED DATA TRANSMITTED DATA NO CONNECTION SIGNAL GROUND NO CONNECTION RTS CTS NO CONNECTION SIZE A

1
6
2
7 DETAIL A DE-9S
3
8
4
9
5
PIN 1 2 3 4 5 6 7 8 9 SCALE N/A
2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME.
6.75 171.45 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL.
3. DIMENSIONS ARE IN INCHES [mm]. CAD FILE 041317 1

MOMENTARY SWITCH FOR MANUAL CONTROL

NOTES:

2-PLACES TAP TO STEP HOLD TO JOG DETAIL A A THIS UNIT IS SUPPLIED WITH A 12 VOLT TRANSFORMER(100-240VAC) DWG TITLE PE70A5013 CAGE CODE 53919

R
THE ENGINEER'S RF SOURCE www.pasternack.com PE70A5013 6.75 171.45 SWITCHCRAFT 712A JACK ACCEPTS .22INCHES Ø PLUG REAR VIEW R

2-PLACES
CURRENT ATTENUATION DISPLAYED SEE NOTE NOTE : THE ENGINEER'S RF SOURCE Pasternack Enterprises, Inc. P.O. Box 16759 | Irvine | CA | 92623 Phone: (949) 261-1920 | Fax: (949) 261-7451 Website: www.pasternack.com | E-Mail: sales@pasternack.com

SMA FEMALE 4-PLACES 3.25 82.55 STANDARD TOLERANCES .XX ±0.010 .XXX ±0.005 *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES

.15 3.81

PE70A5013 REV 1.0 9
