PE3C5892 CAD Drawing
Plenum N Male to SMA Male Right Angle Low PIM Cable
Using SPP-250-LLPL Coax , LF Solder
CN2379
SIZE A
N MALE
6'' FROM CABLE END 1 PLACE. 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL. 2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME. SCALE N/A
.75 [19.0]
HEX
SERIAL # PIM LEVEL -zzzdBc PIM LABEL NOTES: 3. DIMENSIONS ARE IN INCHES [mm]. 12/26/18 CAD FILE
LENGTH MEASURED FROM CONTACT TO END - LABEL CENTERED 84'' OR LESS. - GREATER THAN 84'' LABEL 2 PLACES 12'' FROM CABLE END. PE3C5892 CAGE CODE 53919
www.PASTERNACK.com PART # PE LABEL DWG TITLE
R
P.O. Box 16759 | Irvine | CA | 92623
SPP-250-LLPL THE ENGINEER'S RF SOURCE
Pasternack Enterprises, Inc.
HEAT SHRINK PROTECTOR Pasternack does not make Phone: (949) 261-1920 | Fax: (949) 261-7451 Website: www.pasternack.com | E-Mail: sales@pasternack.com
(2X)
.32 [8.0] HEX
.XXX ±0.005
SMA MALE STANDARD TOLERANCES *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES -
.XX ±0.01
.X ±0.2
RA
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.
PE3C5892 REV 1.0 6
