PE4961 CAD Drawing
C Female Connector Clamp/Solder Attachment for RG55, RG58, RG141,
RG142, RG223, RG303, RG400, PE-C195, PE-P195, LMR-195

7361
HEX. NUT

GASKET SIZE A

.437 [11.10] HEX. CONTACT 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL.
.221 2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME. SCALE N/A
5.61

BRAID CLAMP 3. DIMENSIONS ARE IN INCHES [mm]. 01/03/19 CAD FILE

1.28 32.5 REF. NOTES:
1.155 29.34

.500 12.70 50 Ohm C FEMALE

BODY PE4961 CAGE CODE 53919

.535 13.59 DWG TITLE

Pasternack does not make Phone: (949) 261-1920 | Fax: (949) 261-7451
R
THE ENGINEER'S RF SOURCE Pasternack Enterprises, Inc. P.O. Box 16759 | Irvine | CA | 92623 Website: www.pasternack.com | E-Mail: sales@pasternack.com

.559 14.20 FLATS

STANDARD TOLERANCES *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES -

.XXX ±0.005
.XX ±0.01
.X ±0.2

any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.

PE4961 REV 1.2 5
