PE44649Z CAD Drawing
FAKRA Plug Connector Solder Attachment Thru Hole PCB, Water Blue Color

2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME.

.200 5.08 SQ. 7361

SIZE A

.276 7.00 SQ.
SCALE N/A

.040 1.02 SQ.
.038 0.96 4X 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL.
.200 5.08 SQ. 3. DIMENSIONS ARE IN INCHES [mm]. 091417

.047 1.20 CAD FILE
PCB LAYOUTS NOTES:

.697 17.70 REF .543 13.80 REF
.067 1.70 .100 2.54

PE44649Z CAGE CODE 53919
4X
.100 2.54
DWG TITLE

.374 9.50 SQ
R
THE ENGINEER'S RF SOURCE

.433 11.00

Pasternack Enterprises, Inc. P.O. Box 16759 | Irvine | CA | 92623 Phone: (949) 261-1920 | Fax: (949) 261-7451 Website: www.pasternack.com | E-Mail: sales@pasternack.com
STANDARD TOLERANCES .X ±0.2 .XX ±0.01 .XXX ±0.005 *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES

PE44649Z REV 1.2 3
