75 Ohm 1.0/2.3 Jack Right Angle Bulkhead Mount Push-
On Connector Solder Attachment Thru Hole PCB

RF Connectors Technical Data Sheet PE45230

Material Specifications
Description Material Plating
Contact Phosphor Bronze Gold

Insulation PTFE
Outer Conductor Brass Gold
Body Brass Gold

.

Environmental Specifications
Temperature
Operating Range -40 to 155 deg C

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:

75 Ohm 1.0/2.3 Jack Right Angle Bulkhead Mount Push-On Connector Solder Attachment Thru Hole PCB from Pasternack
Enterprises has same day shipment for domestic and International orders. Our RF, microwave and millimeter wave products
maintain a 99% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: 75 Ohm 1.0/2.3 Jack Right Angle Bulkhead Mount Push-On Connector Solder Attachment Thru
Hole PCB PE45230

URL: https://www.pasternack.com/1.0-2.3-jack-push-on-thru-hole-pcb-connector-pe45230-p.aspx

PE45230 REV 1.0 2
