MMCX Plug Connector Solder Attachment for PE-047SR, PE-SR047AL, PE-SR047FL

Name: MMCX Plug Connector Solder Attachment for PE-047SR, PE-SR047AL, PE-SR047FL
Brand: Pasternack
SKU: PE44456
Availability: InStock

Product ID: PE44456

Pricing

Quantity	Price
1-24	$30.19
25-49	$28.68
50-99	$27.17
100-249	$25.96
250+	Call Us

* All Prices are in US Dollars and do not include duties

Buy

How many?

Available Quantity: 112

Same-Day Shipping!

Order in the next hours!

* All Prices are in US Dollars and do not include duties

View
Datasheet

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
Polarity	Standard
Connector Series	MMCX
Connector Gender	Plug
Impedance	50 Ohm
Body Style	Straight
Attachment Method	Solder
Mount Method	None
Minimum Frequency	DC
Maximum Frequency	6 GHz
Interface Type 1	PE-047SR
Interface Type 2	PE-SR047AL
Interface Type 3	PE-SR047FL

Description

MMCX Plug Connector Solder Attachment for PE-047SR, PE-SR047AL, PE-SR047FL

PE44456 MMCX plug coaxial connector has an interface type of PE-047SR, PE-SR047AL, PE-SR047FL and a 50 Ohm impedance. Pasternack MMCX plug connector uses shield/contact solder as an attachment method. Our plug MMCX coaxial connector provides a minimum frequency of DC and a maximum frequency of 6 GHz.

The Pasternack MMCX plug coaxial connector has a PTFE dielectric type. The Pasternack MMCX coaxial connector has a brass body with gold plating. Our PE44456 MMCX connector uses brass contact. This MMCX plug coaxial RF connector is RoHS and REACH compliant.

This Pasternack plug MMCX connector will ship the same day as purchased. Our MMCX plug connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom MMCX connector cable assemblies that will ship the same day as well.
