30 dB Fixed Attenuator, N Male to N Female Black Anodized
Aluminum Heatsink Body Rated to 50 Watts Up to 4 GHz

RF Fixed Attenuators Technical Data Sheet PE7394-30

Typical Performance Data

Return Loss
0
-10

-20

-30
dB
-40

-50 S11
-60 S22
Max
-70
0 0.5 1 1.5 2 2.5 3 3.5 4
Freq (GHz)

Attenuation
-26

-27
-28
-29

dB -30
-31
-32

-33
-34
0 0.5 1 1.5 2 2.5 3 3.5 4
Freq (GHz)

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: 30 dB Fixed Attenuator, N Male to N Female Black Anodized Aluminum Heatsink Body Rated
to 50 Watts Up to 4 GHz PE7394-30

PE7394-30 REV 1.1 3
