Slide-On BMA Plug Bulkhead to Snap-On BMA
Jack Cable Using LMR-100 Coax

RF Cable Assemblies Technical Data Sheet PE3C4925

Typical Performance Data
2 HOLE FLANGE CUTOUT

2X
#2-56 UNC-2B
PANEL CUTOUT
.378 +.000
-.002
.500±.003 9.60 0.00
12.70±0.07 -0.05
.450 +.001
-.000
11.43 +0.03 .559±.004
0.00
14.20±0.10

+.002
.341 -.000 .317±.001 MOUNTING HOLE
8.66 +0.05 8.05±0.02
0.00

BMA JACK BULKHEAD CUTOUT

.320 +.001
-.000
PANEL DRILLING +0.03
8.13 0.00
BMA PLUG BULKHEAD CUTOUT
.243
.242
6.17
6.15

MOUNTING HOLE

MOUNTING HOLE

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: Slide-On BMA Plug Bulkhead to Snap-On BMA Jack Cable Using LMR-100 Coax PE3C4925
.243
.242
6.17 Pasternack does not make -
6.15
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.
