PE34221 CAD Drawing
N Male Right Angle to N Female Bulkhead Cable Using RG225 Coax
APPROVED S.ELLIS 1 N/A REV A
THE INFORMATION AND DESIGN IN THIS DOCUMENT IS THE PROPERTY OF PASTERNACK CORPORATION. ALL RIGHTS RESERVED. SHEET OF 1
DATE 07/23/19 .917 23.29 SCALE
N FEMALE BULKHEAD MOUNTING HOLE PE34221
REVISIONS 3/4 HEX PART NUMBER
DESCRIPTION INITIAL RELEASE .327 8.30 MAX. PANEL Pasternack Enterprises, Inc. P.O.Box 16759, Irvine, CA 92623. Phone: 1.949.261.1920 │ 1.866.727.8376 Fax: 1.949.261.7451 www.pasternack.com │ e-mail: sales@pasternack.com
.535 +.005 -.000 13.59 +0.13 0.00 .630 +.005 -.000 16.00 +0.13 0.00 DRAWN BY K.DANG
REV. A Ø CAGE SIZE 53919 A
UNLESS OTHERWISE SPECIFIED LEADING DIMENSIONS ARE INCHES DIMENSIONS IN [ ] ARE MILLIMETERS TOLERANCES: FRACTIONS .2 [5.08] .X=± ± 1/32 .01 [ .25 ] .XX=± ANGLES ± 1° .005 [ .13 ] .XXX=± ALL DIMENSIONS SHOWN ARE FOR REFERENCE ONLY. THIRD-ANGLE PROJECTION
LENGTH MEASURED FROM CONTACT TO FLANGE RG225/U
HEAT SHRINK SLEEVE THESE COMMODITIES, TECHNOLOGY OR SOFTWARE WERE EXPORTED FROM THE UNITED STATES IN ACCORDANCE WITH THE EXPORT ADMINISTRATION REGULATIONS. DIVERSION CONTRARY TO U.S. LAW PROHIBITED.
2X
CONTACT N MALE RA Pasternack does not make -
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.
T-Rev.B
PE34221 REV 1.1 4
