Page 2350 - NEX10 to SMA RF Cable Assembly Datasheets

SMA Male Right Angle to SMA Female Bulkhead
Cable Using PE-SR401AL Coax

RF Cable Assemblies Technical Data Sheet PE34317

Configuration
• Connector 1: SMA Male Right Angle
• Connector 2: SMA Female Bulkhead
• Cable Type: PE-SR401AL-STRAIGHT

Features
• Max Frequency 18 GHz
• 69.5% Phase Velocity

Applications

• General Purpose • Laboratory Use
.
Description
Pasternack’s PE34317 SMA male right angle to SMA female bulkhead cable using PE-SR401AL coax is part of our full line of
RF components available for same-day shipping. Pasternack’s semi-rigid RF cable assemblies are ideal for high performance
applications and can be formed, using proper tooling, to the routing pattern required. This Pasternack SMA to SMA cable
assembly has a male to female gender configuration with 50 ohm semi-rigid PE-SR401AL-STRAIGHT coax. The PE34317
SMA male to SMA female cable assembly operates to 18 GHz. The right angle SMA interface on the PE-SR401AL-STRAIGHT
cable allows for easier connections in tight spaces. Our RF cable assembly with SMA bulkhead interface allows designers to
create external connections on their product enclosures, and can be used in a variety of other rack mount and panel mount
applications.
Custom versions of most RF cable assemblies can be built and shipped same day. Custom cable assembly lengths can be
obtained by specifying the desired length on the web site at time of order or by contacting a sales representative. Other avail-
able RF cable assembly value added services include connector orientation or clocking, heat shrink booting and custom label-
ing. RF testing can also be performed to document the electrical performance of your cable assembly.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: SMA Male Right Angle to SMA Female Bulkhead Cable Using PE-SR401AL Coax PE34317
-
Pasternack does not make
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.

PE34317 REV 1.1 1
