3/4 inch-20 Twinax Male to 3/4 inch-20 Twinax
Male Cable Using 100 Ohm PE-S330 Coax

TECHNICAL D PE3930
TECHNICAL DATA SHEETATA SHEET

Inner Conductor Plating Specification 30µ in. minimum
Body Material and Plating Brass, Nickel
Body Plating Specification 100µ in. minimum
Dielectric Type PBT

Connector 2
Type 3/4”-20 Twinax Male
Configuration Straight
Inner Conductor Material and Plating Brass, Gold
Inner Conductor Plating Specification 30µ in. minimum
Body Material and Plating Brass, Nickel
Body Plating Specification 100µ in. minimum
Dielectric Type PBT

Compliance Certifications (visit www.Pasternack.com for current document)
For RoHS Compliant version, use PE3930LF. Contact Pasternack if product cannot be found.
Plotted and Other Data
Notes:
• Values at +25 °C, sea level

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: 3/4 inch-20 Twinax Male to 3/4 inch-20 Twinax Male Cable Using 100 Ohm PE-S330 Coax
PE3930

PE3930 REV 2
