SMP Female Right Angle to SMP Female
Right Angle Cable Using PE-P047 Coax

RF Cable Assemblies Technical Data Sheet PE3C4969

Mechanical Specification Notes:
*All cable assemblies have a length tolerance of 1.5% or ± 3/8”, whichever is greater.

Environmental Specifications
Temperature
Operating Range -55 to +125 deg C

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:
Typical Performance Data
PE3C4969-36 VSWR
2.00
1.90
1.80
1.70
1.60
1.50
1.40
1.30
1.20
1.10
1.00
0.0 GHz 1.8 3.6 5.4 7.2 9.0 10.8 12.6 14.4 16.2 18.0

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: SMP Female Right Angle to SMP Female Right Angle Cable Using PE-P047 Coax PE3C4969
-
