TNC Female Bulkhead to MMCX Plug
Right Angle Semi-Flexible Cable Using PE-SR405FLJ
Coax with HeatShrink, LF Solder, RoHS

RF Cable Assemblies Technical Data Sheet PE39492

Environmental Specifications
Temperature
Operating Range -65 to +125 deg C

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:
• Values at 25°C, sea level.

How to Order
Part Number Configuration: PE39492 - xx uu
| | | | | Unit of Measure:
| | cm = Centimeters
<blank> = Inches
| | Length
Base Number
Example: PE39492-12 = 12 inches long cable
PE39492-100cm = 100 cm long cable

TNC Female Bulkhead to MMCX Plug Right Angle Semi-Flexible Cable Using PE-SR405FLJ Coax with HeatShrink,
LF Solder, RoHS from Pasternack Enterprises has same day shipment for domestic and International orders. Our RF,
microwave and millimeter wave products maintain a 99.4% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: TNC Female Bulkhead to MMCX Plug Right Angle Semi-Flexible Cable Using PE-SR405FLJ
Coax with HeatShrink, LF Solder, RoHS PE39492

URL: https://www.pasternack.com/tnc-female-mmcx-plug-pe-sr405flj-cable-assembly-pe39492-p.aspx

PE39492 REV 1.3 3
