PE39478 CAD Drawing
TNC Female Bulkhead to MMCX Plug Right Angle Semi-Flexible
Precision Cable Using PE-SR405FL Coax, LF Solder

APPROVED S.ELLIS THE INFORMATION AND DESIGN IN THIS DOCUMENT IS THE PROPERTY OF PASTERNACK CORPORATION. ALL RIGHTS RESERVED. 1 1 N/A REV A

DATE 10/09/19 5/8 HEX SHEET OF SCALE PE39478

REVISIONS .708 17.98 -.000 0.00 PART NUMBER

DESCRIPTION INITIAL RELEASE TNC FEMALE BULKHEAD .472 +.005 11.99 +0.13 MOUNTING HOLE Pasternack Enterprises, Inc. P.O.Box 16759, Irvine, CA 92623. Phone: 1.949.261.1920 │ 1.866.727.8376 Fax: 1.949.261.7451 www.pasternack.com │ e-mail: sales@pasternack.com DRAWN BY K.DANG

MAX. PANEL 2.29 17.50mm HEX .505 +.005 -.000 0.00 CAGE CODE
.090
REV. A 3/8 HEX 12.83 +0.13 53919

SOLDER Ø FRACTIONS ± 1/32 ANGLES ± 1° SIZE A

UNLESS OTHERWISE SPECIFIED LEADING DIMENSIONS ARE INCHES DIMENSIONS IN [ ] ARE MILLIMETERS TOLERANCES: .2 [5.08] .X=± .01 [ .25 ] .XX=± .005 [ .13 ] .XXX=± ALL DIMENSIONS SHOWN ARE FOR REFERENCE ONLY. THIRD-ANGLE PROJECTION

LENGTH MEASURED FROM CONTACT TO FLANGE PE-SR405FL

SOLDER THESE COMMODITIES, TECHNOLOGY OR SOFTWARE WERE EXPORTED FROM THE UNITED STATES IN ACCORDANCE WITH THE EXPORT ADMINISTRATION REGULATIONS. DIVERSION CONTRARY TO U.S. LAW PROHIBITED.

Pasternack does not make
CONTACT MMCX PLUG RA
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation. -

T-Rev.B
PE39478 REV 1.2 4
