PE3M0246 CAD Drawing
Temperature Conditioned TNC Male Right Angle to N Male
Right Angle Low Loss Cable Using PE-P300LL Coax
APPROVED D.BIRCH 1.15 29.1 RP 1 N/A REV A
THE INFORMATION AND DESIGN IN THIS DOCUMENT IS THE PROPERTY OF PASTERNACK CORPORATION. ALL RIGHTS RESERVED. SHEET OF 1
DATE 02/08/19 CONTACT PE45225 N MALE RIGHT ANGLE SCALE PE3M0246
REVISIONS PART NUMBER
DESCRIPTION INITIAL RELEASE 9/16 FLATS P2 CAGE 53919 3/4 HEX Pasternack Enterprises, Inc. P.O.Box 16759, Irvine, CA 92623. Phone: 1.949.261.1920 │ 1.866.727.8376 Fax: 1.949.261.7451 www.pasternack.com │ e-mail: sales@pasternack.com DRAWN BY K.DANG
REV. A CAGE SIZE 53919 A
2 FRACTIONS ± 1/32 ANGLES ± 1°
UNLESS OTHERWISE SPECIFIED LEADING DIMENSIONS ARE INCHES DIMENSIONS IN [ ] ARE MILLIMETERS TOLERANCES: .2 [5.08] .X=± .01 [ .25 ] .XX=± .005 [ .13 ] .XXX=± ALL DIMENSIONS SHOWN ARE FOR REFERENCE ONLY. THIRD-ANGLE PROJECTION
LENGTH MEASURED FROM CONTACT TO CONTACT PASTERNACK PE3M0246-XXX SN XXXX D/C WWYY PE-P300LL
2 THESE COMMODITIES, TECHNOLOGY OR SOFTWARE WERE EXPORTED FROM THE UNITED STATES IN ACCORDANCE WITH THE EXPORT ADMINISTRATION REGULATIONS. DIVERSION CONTRARY TO U.S. LAW PROHIBITED.
.39 [10.0] FLATS P1 9/16 HEX ALL BLACK HEAT SHRINK WITH WHITE MARKINGS. TOP LAYER: SUMITUBE W3B2 (4X) - SIZE 24/6.
CONTACT PE45526 TNC MALE RIGHT ANGLE BOTTOM LAYER: M23053/4-304-0. -
Pasternack does not make
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.
1.04 26.5 RP
NOTES: 1. 2.
T-Rev.A
PE3M0246 REV 1.2 7
