BNC Female Bulkhead Mount Connector Clamp/Solder
Attachment for RG178, RG196, .480 inch D Hole

RF Connectors
Technical Data Sheet PE4391

Configuration
• BNC Female Connector • RG178, RG196 Interface Type
• 50 Ohms • Clamp/Solder Attachment
• Straight Body Geometry • Bulkhead
Applications
• General Purpose Test • Rack and Panel Mount Applications • Custom Cable Assemblies
.
Description
Pasternack’s PE4391 BNC female bulkhead connector with clamp/solder attachment for RG178 and RG196 (.480 inch D
hole) is part of our full line of RF components available for same-day shipping. This BNC bulkhead connector allows designers
to create external connections on their product enclosures, and can be used in a variety of other rack mount and panel mount
applications.
Our BNC female bulkhead connector PE4391 datasheet specifications and drawing with dimensions are shown below in
this PDF. Pasternack’s broad catalog of RF, microwave and millimeter wave connectors allows designers to configure and
customize their signal connections however they like. Whether the need is to provide an I/O for a board design, or simply
create a custom cable assembly configuration, Pasternack has the right connector for the job. Pasternack can also expertly
build your custom cable assemblies for you and ship same-day.

Mechanical Specifications
.
Weight 0.055 lbs [24.95 g]
.
Material Specifications
Description Material Plating
Body Brass Nickel
.

Environmental Specifications

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including
price, inventory and certifications: BNC Female Bulkhead Mount Connector Clamp/Solder Attachment for RG178, RG196,
-
.480 inch D Hole PE4391 Pasternack does not make
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.

PE4391 REV 1.2 1
