Page 1200 - TNC to Double Banana RF Connector Datasheets

Double Banana Plug Connector Crimp/Solder Attachment for
PE-C195, PE-P195, RG58, RG141, RG303, LMR-195, .195 inch

RF Connectors
Technical Data Sheet PE4301

Environmental Specifications

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:

Assembly Instruction

.500
12.70

.100 .300
2.54 7.62

STRIPPING DIMENSIONS

CRIMP SIZE REQUIRED

• CONTACT: .068 [1.73] HEX CRIMP TOOL.
• FERRULE: .100 [2.54] HEX CRIMP TOOL.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: Double Banana Plug Connector Crimp/Solder Attachment for PE-C195, PE-P195, RG58, -
RG141, RG303, LMR-195, .195 inch PE4301 Pasternack does not make
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.
