Standard SMC 0.5 Watt Dummy Loads

Check out our new RF calculators & conversion tools...

0.5 Watt RF Load Up to 1,000 MHz with SMC Plug Nickel Plated Brass

Product ID: PE6049
0.5 Watt RF Load Up to 1,000 MHz with SMC Plug Nickel Plated Brass


Image Views:  0.5 Watt RF Load Up to 1,000 MHz with SMC Plug Nickel Plated Brass high resolution
Zoomalternate image
View 2


Click for:PE6049 Datasheet
DISCONTINUED PRODUCT
Replaced By: PE6TR006

Key Specifications (Click on Data Sheet Above for Additional Details).
Termination TypeRF Load
Connector SeriesSMC
Connector GenderPlug
Minimum FrequencyDC
Maximum Frequency1 GHz
Impedance50 Ohm
Maximum Power0.5 Watt


0.5 Watt RF Load Up to 1,000 MHz with SMC Plug Nickel Plated Brass

PE6049 0.5 Watts RF load (also known as termination or dummy load) has a SMC connector that is plug. This Pasternack 0.5 watt SMC plug load / termination is rated for a maximum frequency of 1 GHz. Our SMC plug termination load is a rf load termination with a 50 Ohm impedance.

This SMC load / coax terminator is manufactured with no chain. PE6049 0.5 watt SMC plug load termination is one of over 40,000 RF, microwave and millimeter wave components in-stock at Pasternack. Our SMC plug 0.5 watt termination load will ship worldwide the same day as purchased.
