250 MHz to 2.5 GHz SMA Bias Tee Rated to 7000 mA and 100 Volts DC

Product ID: PE1617

Pricing

QuantityPrice
1-4$732.38
5-9$695.76
10-24$659.14
25+Call Us

* All Prices are in US Dollars and do not include duties

Buy

Available Quantity: 10
Shipping Truck
Same-Day Shipping!
Order in the next hours!
* All Prices are in US Dollars and do not include duties

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
RF Port Connector SeriesSMA
DC Port Connector SeriesSolder Pin
Minimum Frequency250 MHz
Maximum Frequency2.5 GHz
Maximum Voltage100 Volts
Maximum DC Current7,000 mA

Description

250 MHz to 2.5 GHz SMA Bias Tee Rated to 7000 mA and 100 Volts DC

PE1617 bias tee (also called bias T) has an SMA connector RF port that is female gender. This Pasternack female SMA bias tee design is rated for a minimum frequency of 250 MHz and a maximum frequency of 2.5 GHz. Our RF coaxial bias tee has a solder pin DC port connector with a female gender.

This SMA bias tee / T is rated for a max. DC voltage of 100 Volts and a max. current of 7,000 mA. The PE1617 bias T with SMA connector series for RF port is designed with a maximum VSWR of and a RF to bias isolation minimum of 20 dB. Pasternack's radio frequency bias tee is one of over 40,000 RF, microwave and millimeter wave components supplied by us. Our coaxial SMA bias T can be purchased and will be shipped worldwide the same-day as with other in-stock Pasternack RF parts.
