4.1/9.5 Mini DIN Male Right Angle Connector Solder Attachment for SPP-250-LLPL, Low PIM

PE45422 4.1/9.5 Mini DIN male right angle coaxial connector has an interface type of SPP-250-LLPL and a 50 Ohm impedance. Pasternack 4.1/9.5 Mini DIN male connector uses shield/contact solder/solder as an attachment method. Our male 4.1/9.5 Mini DIN right angle coaxial connector provides a minimum frequency of DC and a maximum frequency of 6 GHz.

The Pasternack right angle 4.1/9.5 Mini DIN male coaxial connector has a PTFE dielectric type and a VSWR of 1.3. The Pasternack 4.1/9.5 Mini DIN coaxial connector has a brass body with tri-metal plating. Our PE45422 4.1/9.5 Mini DINright angle connector uses brass contact. This 4.1/9.5 Mini DIN male right angle coaxial RF connector is RoHS and REACH compliant.

This Pasternack right angle male 4.1/9.5 Mini DIN connector will ship the same day as purchased. Our 4.1/9.5 Mini DIN right angle male connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom 4.1/9.5 Mini DIN connector cable assemblies that will ship the same day as well.
