4.3-10 Male to N Male Right Angle Cable Using LMR-LW240 Coax with Double HeatShrink

Name: 4.3-10 Male to N Male Right Angle Cable Using LMR-LW240 Coax with Double HeatShrink
Brand: Pasternack
SKU: PE3C10147/HS2
Availability: OutOfStock

Product ID: PE3C10147/HS2

Length

Custom Length

* Lengths are rounded to the nearest quarter inch or centimeter. For precise lengths, please call 866-727-8376.

* All cable assembly length tolerance are as provided on the datasheet. If not provided, cable length tolerances are within the IPC standards (2022-24) as shown here.

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1	4.3-10
Connector Gender 1	Male
Connector Polarity 1	Standard
Connector Angle 1	Straight
Connector Mount Method 1	None
Connector Impedance 1	50 Ohm
Connector Series 2	N
Connector Gender 2	Male
Connector Polarity 2	Standard
Connector Angle 2	Right Angle
Connector Mount Method 2	None
Connector Impedance 2	50 Ohm
RF Cable Part Number	LMR-LW240
RF Cable Type	LMR-LW240
RF Cable Impedance	50 Ohm

Description

Click on the below images to access KitBOM product pages:


EZ-240-4310M-X	LMR-LW240	EZ-240-NMH-RA-X	KitBOM Datasheet

4.3-10 Male to N Male Right Angle Cable Using LMR-LW240 Coax with Double HeatShrink

PE3C10147/HS2 is a 4.3-10 male to N male right angle cable using LMR-LW240 coax. This Pasternack 4.3-10 male to N male right angle cable assembly uses a 50 Ohm 4.3-10 for connector 1 and a 50 Ohm N for connector 2. 4.3-10 to N right angle coaxial cable assembly uses 90 degree right angle coax cable connector.

Our male 4.3-10 to male N right angle cable assembly uses a flexible cable type that is 50 Ohm. Pasternack PE3C10147/HS2 4.3-10 male to N male right angle cable assembly is constructed with LMR-LW240 coax.

* LMR™ is a trademark of Times Microwave Systems.
