Temperature Compensated Low Noise Amplifier, 0.5 GHz to 4 GHz, 35 dB min Gain, P1dB 20 dBm, SMA
Product ID:
PE15A5101
Pricing
| Quantity | Price |
| 1-4 | $4,950.00 |
* All Prices are in US Dollars and do not include duties
Buy
Available Quantity: 1

Same-Day Shipping!
Order in the next hours!
* All Prices are in US Dollars and do not include duties
Key Specifications
| Key Specifications (Click on Data Sheet Above for Additional Details). |
| Frequency, Min | 500 MHz |
| Frequency, Max | 4 GHz |
| Gain, Min | 35 dB |
| Gain, Typical | 47 dB |
| 1dB Compression Point, Min | 20 dBm |
| Voltage, DC Max | 15 Volts |
Description
Temperature Compensated Low Noise Amplifier, 0.5 GHz to 4 GHz, 35 dB min Gain, P1dB 21 dBm, SMA
The PE15A5101 is a temperature compensated low noise amplifier designed for SMA-connected RF signal paths, offering 50 Ohm impedance and 500 MHz to 4 GHz operation. It supports RF and electronic system integration where stable gain and low noise are needed across changing operating temperatures. This amplifier provides 35 dB minimum gain, 20 dBm minimum P1dB, and typical 4 noise performance with 1.4:1 typical VSWR.
Frequently Asked Questions
What is the PE15A5101 low noise amplifier used for?
The PE15A5101 is a temperature compensated low noise amplifier used to boost RF signals in 50 Ohm SMA-connected signal chains. It supports 500 MHz to 4 GHz operation, provides 35 dB minimum gain, and reaches 20 dBm minimum P1dB performance. Engineers use it in receiver paths, lab setups, and electronic subsystems that need broadband gain across changing temperatures. Its SMA female connectors and typical 1.4:1 input and output VSWR help simplify integration into established RF assemblies.
Why would engineers choose a temperature compensated amplifier?
Engineers choose the PE15A5101 when signal chains need amplification that remains more stable as ambient temperatures change during operation. This model operates from -55°C to 85°C, covers 500 MHz to 4 GHz, and provides 35 dB minimum gain. That combination is useful in outdoor electronics, variable-environment test systems, and installed RF assemblies with shifting thermal conditions. Temperature compensation helps support more predictable amplifier behavior when equipment moves between startup, steady-state, and elevated operating temperatures.
Can the PE15A5101 be integrated into SMA-based RF test setups?
The PE15A5101 can be integrated directly into SMA-based RF test setups that require broadband gain in standard 50 Ohm paths. It uses SMA female connectors on both ports, supports 500 MHz to 4 GHz coverage, and has typical 1.4:1 VSWR. Engineers place it between instruments, filters, or subsystems when additional signal level is needed before measurement or processing. Its connectorized format also reduces setup complexity by avoiding custom mounting or board-level amplifier implementation in many bench environments.
How does the PE15A5101 balance gain, noise, and output power?
The PE15A5101 balances gain, noise, and output power by combining 35 dB minimum gain with 4.50 maximum noise and 20 dBm minimum P1dB. Those specifications help engineers raise signal levels while maintaining practical noise performance and useful linear output capability. This matters in receiver chains, broadband test benches, and general RF subsystems where weak signals still need downstream headroom. Typical 47 dB gain and 21 typical P1dB also provide additional performance context when comparing amplifier options for system design.
