5 Section Tunable Band Pass Filter With N Female Connectors Operating From 1 GHz to 2 GHz With a 5% Bandwidth

Product ID: PE8732
5 Section Tunable Band Pass Filter With N Female Connectors Operating From 1 GHz to 2 GHz With a 5% Bandwidth


Image Views:  5 Section Tunable Band Pass Filter With N Female Connectors Operating From 1 GHz to 2 GHz With a 5% Bandwidth high resolution
Zoomalternate image
View 2


Click for:PE8732 Datasheet
Click for:PE8732 REACH Cert
Available Quantity: 8
Pricing Table
QUANTITYPRICE
1-24$2,193.06
25-49$2,039.55
50-99$1,886.03
100-249$1,754.45
250+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
TypeBand Pass
DesignTunable
Min Frequency1,000 MHz
Max Frequency2 GHz
Maximum Insertion Loss1 dB
Impedance50 Ohm
Input Max VSWR1.5:1
Maximum Power50 Watts
Connector-In SeriesN
Connector-In GenderFemale
Connector-Out SeriesN
Connector-Out GenderFemale


5 Section Tunable Band Pass Filter With N Female Connectors Operating From 1 GHz to 2 GHz With a 5% Bandwidth

Tunable bandpass filter PE8732 from Pasternack is part of our extensive in-stock RF components for sale. Our tunable band pass filter is manufactured with N connectors that are female and in a 5 section design. This 5 section N tunable bandpass filter for Band Pass has an VSWR of 1.5 and a maximum power of 50 Watts.

Frequency range of this adjustable band pass filter is 1,000 MHz to 2 GHz and the percentage of bandwidth is 5%. PE8732 adjustable bandpass filter is one of over 40,000 RF, microwave and millimeter wave components supplied by Pasternack. Our 5 section variable bandpass filter can be bought and shipped worldwide the same-day as with our other in-stock RF parts.
