N 8 Way Power Dividers 50 Ohm

Check out our new RF calculators & conversion tools...

8 Way N Wilkinson Power Divider From 690 MHz to 2.7 GHz Rated at 10 Watts

Product ID: PE2095
8 Way N Wilkinson Power Divider From 690 MHz to 2.7 GHz Rated at 10 Watts


Image Views:  8 Way N Wilkinson Power Divider From 690 MHz to 2.7 GHz Rated at 10 Watts high resolution
Zoomalternate image
View 2


Click for:PE2095 Datasheet
Click for:PE2095 RoHS Cert
Click for:PE2095 REACH Cert
Available Quantity: 31
Pricing Table
QUANTITYPRICE
1-9$403.85
10-24$383.66
25-49$363.47
50+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series InN
Connector Gender InFemale
Minimum Frequency690 MHz
Maximum Frequency2.7 GHz
Number of Output Ports8 Port
Impedance50 Ohm
Maximum Input Power10 Watt


8 Way N Wilkinson Power Divider From 690 MHz to 2.7 GHz Rated at 10 Watts

PE2095 8 way type N power divider (also known as a type N coaxial power splitter) is rated for a minimum frequency of 690 MHz and a maximum frequency of 2.7 GHz. This Pasternack 8 port type N power divider / coaxial splitter has a 50 Ohm impedance and a maxium input power of 10 Watts. Our N type coaxial RF splitter / divider has a female type N input and 8 female N type output ports.

This 8 way type N RF power divider from Pasternack is a wilkinson design and has a maximum insertion loss of 0. The maximum input VSWR of this type N wilkinson splitter / divider is 1.4:1 and the minimum isolation is 20 dB. Our 8 port type N power divider is one of over 40,000 RF, microwave and millimeter wave components supplied by Pasternack. This wilkinson 8 way type N female coaxial RF power divider splitter can be bought and shipped worldwide the same-day as with Pasternack's other in-stock RF parts.
