Banana Plug to SHV Jack Bulkhead Cable Using RG223 Coax with HeatShrink

Product ID: PE3W02799/HS

Length

* Lengths are rounded to the nearest quarter inch or centimeter. For precise lengths, please call 866-727-8376.
* Lengths are rounded to the nearest quarter inch or centimeter. For precise lengths, please call 866-727-8376.

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1Banana
Connector Gender 1Plug
Connector Polarity 1Standard
Connector Angle 1Straight
Connector Mount Method 1None
Connector Series 2SHV
Connector Gender 2Jack
Connector Polarity 2Standard
Connector Angle 2Straight
Connector Mount Method 2Bulkhead
Connector Impedance 250 Ohm
RF Cable Part NumberRG223/U
RF Cable TypeRG223
RF Cable Impedance50 Ohm

Description

Click on the below images to access KitBOM product pages:


PE4089RG223/UPE44080KitBOM Datasheet

Banana Plug to SHV Jack Bulkhead Cable Using RG223 Coax with HeatShrink

PE3W02799/HS is a Banana plug to SHV jack bulkhead cable using RG223 coax. This Pasternack Banana plug to SHV jack bulkhead cable assembly uses a Banana for connector 1 and a 50 Ohm SHV for connector 2.

Our plug Banana to jack SHV bulkhead cable assembly uses a flexible cable type that is 50 Ohm. Pasternack PE3W02799/HS Banana plug to SHV jack bulkhead cable assembly is constructed with RG223 coax.
