BNC Female Straight Connectors

Check out our new RF calculators & conversion tools...

BNC Female Connector Crimp/Solder Attachment for PE-C195, PE-P195, RG58, RG141, RG303, LMR-195, 0.195 inch

Product ID: PE4070
BNC Female Connector Crimp/Solder Attachment for PE-C195, PE-P195, RG58, RG141, RG303, LMR-195, 0.195 inch


Image Views:  BNC Female Connector Crimp/Solder Attachment for PE-C195, PE-P195, RG58, RG141, RG303, LMR-195, 0.195 inch high resolution
Zoomalternate image
View 2


Click for:PE4070 Datasheet
Click for:PE4070 RoHS Cert
Click for:PE4070 REACH Cert
Available Quantity: 1,401
Pricing Table
QUANTITYPRICE
1-24$8.55
25-49$7.95
50-99$7.35
100-249$6.84
250+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
PolarityStandard
Connector SeriesBNC
Connector GenderFemale
Impedance50 Ohm
Body StyleStraight
Attachment MethodCrimp/Solder
Mount MethodNone
Minimum FrequencyDC
Maximum Frequency4 GHz


BNC Female Connector Crimp/Solder Attachment For RG58

PE4070 BNC female coaxial connector has an interface type of RG58 and a 50 Ohm impedance. Pasternack BNC female connector uses shield/contact crimp/solder as an attachment method. Our female BNC coaxial connector provides a minimum frequency of DC and a maximum frequency of 4 GHz.

The Pasternack BNC female coaxial connector has a teflon dielectric type and a VSWR of 1.3. The Pasternack BNC coaxial connector has a brass body with nickel plating. Our PE4070 BNC connector uses brass contact. This BNC female coaxial RF connector is RoHS and REACH compliant.

This Pasternack female BNC connector will ship the same day as purchased. Our BNC female connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom BNC connector cable assemblies that will ship the same day as well.
