D-Sub Plug Straight Connectors

Check out our new RF calculators & conversion tools...

D-Sub Plug Contact Solder Attachment For RG174, RG316, RG187, RG188

Product ID: PE4813
D-Sub Plug Contact Solder Attachment For RG174, RG316, RG187, RG188


Image Views:  D-Sub Plug Contact Solder Attachment For RG174, RG316, RG187, RG188 high resolution
Zoomalternate image
View 2


Click for:PE4813 Datasheet
DISCONTINUED PRODUCT
Search for alternative
Connectors.

Key Specifications (Click on Data Sheet Above for Additional Details).
PolarityStandard
Connector SeriesD-Sub
Connector GenderPlug
Impedance50 Ohm
Body StyleStraight
Attachment MethodSolder/Solder
Mount MethodNone


D-Sub Plug Contact Solder Attachment For RG174, RG316, RG187, RG188

PE4813 D-Sub plug coaxial connector has an interface type of RG174, RG316, RG187, RG188 and a 50 Ohm impedance. Pasternack D-Sub plug connector uses shield/contact solder/solder as an attachment method.

The Pasternack D-Sub coaxial connector has a brass body with gold plating. This D-Sub plug coaxial RF connector is RoHS and REACH compliant.

This Pasternack plug D-Sub connector will ship the same day as purchased. Our D-Sub plug connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom D-Sub connector cable assemblies that will ship the same day as well.
