MCX Jack Straight Connectors

Check out our new RF calculators & conversion tools...

MCX Jack Connector Solder Attachment 4 Hole Flange Solder Cup Terminal, .232 inch Hole Spacing

Product ID: PE4895
MCX Jack Connector Solder Attachment 4 Hole Flange Solder Cup Terminal, .232 inch Hole Spacing


Image Views:  MCX Jack Connector Solder Attachment 4 Hole Flange Solder Cup Terminal, .232 inch Hole Spacing high resolution
Zoomalternate image
View 2


Click for:PE4895 Datasheet
Click for:PE4895 RoHS Cert
Click for:PE4895 REACH Cert
DISCONTINUED PRODUCT
Search for alternative
Connectors.

Key Specifications (Click on Data Sheet Above for Additional Details).
PolarityStandard
Connector SeriesMCX
Connector GenderJack
Impedance50 Ohm
Body StyleStraight
Attachment MethodSolder
Mount Method4 Hole Flange


MCX Jack Connector Solder Attachment 4 Hole Flange Solder Cup Terminal, .232 inch Hole Spacing

PE4895 MCX jack 4 hole flange terminal connector has an interface type of solder cup and a 50 Ohm impedance. Pasternack MCX jack 4 hole flange connector uses shield/contact solder as an attachment method.

The Pasternack MCX jack 4 hole flange terminal connector has a teflon dielectric type. The Pasternack MCX terminal connector has a brass body with gold plating. This MCX jack 4 hole flange terminal RF connector is RoHS and REACH compliant.

This Pasternack jack MCX 4 hole flange connector will ship the same day as purchased. Our 4 hole flange MCX jack connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom MCX connector cable assemblies that will ship the same day as well.
