Radio frequency assembly MCX plug right angle to MCX plug cable using RG316-DS coax with heatshrink from Pasternack is part of one of the largest selections of same-day ship coaxial cables for RF, microwave and millimeter wave interconnect solutions. Pasternack coaxial cable assembly products are used in applications requiring high quality, such as laboratory RF test and measurement, rugged and designed for defense/military, telecom antenna tower component jumper connection, production environments, general use, etc. The MCX plug right angle to MCX plug cable using RG316-DS coax with heatshrink, like our other Pasternack coaxial cable assemblies, will ship the same day, and any custom MCX to MCX cable assembly orders will ship the same business day as well.
Pasternack RF coax cable assembly is built with a right angle MCX cable connection on one end and a MCX cable connection on the other. Our right angle MCX to MCX cable assembly has a plug gender on end 1 and a plug on end 2. PE36981/HS can also be known as a right angle MCX male to MCX male cable assembly and will be shipped the same day as it is purchased. This flexible RF cable assembly with a 0.5-inch diameter has copper clad steel as the cable's inner conducting material and PTFE dielectric type.
This cable assembly employs durable and flexible materials, and with a 1.57-inch bend radius, it can withstand repetitive movements, ensuring reliable performance over extended periods. Our PE36981/HS RF cable has a FEP jacket of 0.114-inch diameter. The flexible RF cable has an in-series connection. This cable assembly has a typical propagation velocity of 69.5% and a minimum RF shielding of 85 dB.
MCX male to MCX male cable assembly PE36981/HS is built with RG316-DS which is a flexible coax type. The Pasternack flexible MCX cable assembly is manufactured with right angle MCX to MCX cable connectors, has a 50 Ohm impedance, and is double shielded. Both the connectors have a crimp/solder attachment method and a brass body with nickel plating. Additional dimensions, specifications and CAD drawings for this RF cable are available on our downloadable PDF datasheet. PE36981/HS can also be used in the other direction and will be a MCX plug to right angle MCX plug cable assembly if the opposite connectivity is required.
MCX right angle male to MCX male cable assembly is just one of more than one million in-stock RF products available. Pasternack is where to buy a high quality MCX to MCX cable assembly for quick shipment worldwide. Variations of MCX cable assemblies can also be built and will ship on the same day as well, search this website or contact us for assistance. High quality custom RF cable assembly products for microwave and millimeter wave radio transmitter receiver, antenna jumper, component interconnection and more for RF test & measurement labs, rugged and MIL-STD designed military/defense, aerospace, telecom, phase stable, phase and delay matching, outdoor and harsh environment and other radio frequency applications can be manufactured. For further information on similar products, our expert technical support and trained sales team can get you the ideal MCX to MCX RF cable assembly as per your requirements.
