MCX Plug Connector Solder Attachment for PE-SR405AL, PE-SR405FL, PE-SR405FLJ, PE-SR405TN, RG405

Name: MCX Plug Connector Solder Attachment for PE-SR405AL, PE-SR405FL, PE-SR405FLJ, PE-SR405TN, RG405
Brand: Pasternack
SKU: PE4876
Availability: InStock

Product ID: PE4876

Pricing

Quantity	Price
1-24	$20.59
25-49	$19.56
50-99	$18.53
100-249	$17.71
250+	Call Us

* All Prices are in US Dollars and do not include duties

Buy

How many?

Available Quantity: 58

Same-Day Shipping!

Order in the next hours!

* All Prices are in US Dollars and do not include duties

View
Datasheet

3D CAD
Model
(.step)

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
Polarity	Standard
Connector Series	MCX
Connector Gender	Plug
Impedance	50 Ohm
Body Style	Straight
Attachment Method	Solder
Mount Method	None
Minimum Frequency	DC
Maximum Frequency	6 GHz
Interface Type 1	PE-SR405AL
Interface Type 2	PE-SR405FL
Interface Type 3	PE-SR405FLJ
Interface Type 4	PE-SR405TN
Interface Type 5	RG405

Description

MCX Plug Connector Solder Attachment for PE-SR405AL, PE-SR405FL, PE-SR405FLJ, PE-SR405TN, RG405

PE4876 MCX plug coaxial connector has an interface type of PE-SR405AL, PE-SR405FL, PE-SR405FLJ, PE-SR405TN, RG405 and a 50 Ohm impedance. Pasternack MCX plug connector uses shield/contact solder as an attachment method. Our plug MCX coaxial connector provides a minimum frequency of DC and a maximum frequency of 6 GHz.

The Pasternack MCX plug coaxial connector has a PTFE dielectric type and a VSWR of 1.37. The Pasternack MCX coaxial connector has a brass body with gold over nickel plating. Our PE4876 MCX connector uses brass contact. This MCX plug coaxial RF connector is RoHS and REACH compliant.

This Pasternack plug MCX connector will ship the same day as purchased. Our MCX plug connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom MCX connector cable assemblies that will ship the same day as well.
