SHV to MHV Adapters Standard Polarity

Check out our new RF calculators & conversion tools...

MHV Female to SHV Jack Adapter

Product ID: PE9339
MHV Female to SHV Jack Adapter

Image Views:  MHV Female to SHV Jack Adapter high resolution
Zoom


Click for:PE9339 Datasheet
Available Quantity: 1,231
Pricing Table
QUANTITYPRICE
1-24$67.60
25-49$64.22
50-99$60.84
100-249$58.14
250+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1MHV
Connector Gender 1Female
Connector Polarity 1Standard
Connector Impedance 150 Ohm
Connector Series 2SHV
Connector Gender 2Jack
Connector Polarity 2Standard
Connector Impedance 250 Ohm
Adapter Body StyleStraight
Connector Mount Method 1None
Connector Mount Method 2None


MHV Female to SHV Jack Adapter

MHV adapter PE9339 is one of over 40,000 available RF, microwave and millimeter wave components from Pasternack. Our MHV to SHV adapter is a between series coaxial adapter design. This 50 Ohm MHV adapter is precision manufactured to RF components industry specifications.

MHV female to SHV jack adapter is one of the many RF components that ship same day as they are ordered. PE9339 female MHV to jack SHV adapter has a straight body. This Pasternack straight MHV coax adapter is a in-line RF adapter.

Our female MHV to jack SHV adapter PE9339 is shipped from Pasternack's ISO 9001:2008 facility the same day as purchased. This MHV to SHV radio frequency adapter is part of over 40,000 RF, microwave and millimeter wave products that ship the same day worldwide, including custom cable assemblies.
