MMCX Jack Straight Connectors

Check out our new RF calculators & conversion tools...

MMCX Jack Connector Solder Attachment Surface Mount PCB

Product ID: PE44662
MMCX Jack Connector Solder Attachment Surface Mount PCB


Image Views:  MMCX Jack Connector Solder Attachment Surface Mount PCB high resolution
Zoomalternate image
View 2


Click for:PE44662 Datasheet
Available Quantity: 45
Pricing Table
QUANTITYPRICE
1-24$20.87
25-49$19.83
50-99$18.78
100-249$17.95
250+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
PolarityStandard
Connector SeriesMMCX
Connector GenderPlug
Impedance50 Ohm
Body StyleStraight
Attachment MethodSolder
Mount MethodNone
Minimum FrequencyDC
Maximum Frequency3 GHz


MMCX Plug Connector Solder Attachment Surface Mount PCB

PE44662 MMCX plug pcb connector has an interface type of surface mount and a 50 Ohm impedance. Pasternack MMCX plug connector uses shield/contact solder as an attachment method. Our plug MMCX pcb connector provides a minimum frequency of DC and a maximum frequency of 3 GHz.

The Pasternack MMCX plug pcb connector has a teflon/lcp dielectric type and a VSWR of 1.5. The Pasternack MMCX pcb connector has a brass body with gold plating. Our PE44662 MMCX connector uses brass/beryllium copper contact. This MMCX plug pcb RF connector is RoHS and REACH compliant.

This Pasternack plug MMCX connector will ship the same day as purchased. Our MMCX plug connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom MMCX connector cable assemblies that will ship the same day as well.
