PE7008-3 CAD Drawing
0 to 65 dB Push Button Step Attenuator, 75 Ohm BNC Female To 75 Ohm
BNC Female With 1 dB Step Rated To 1 Watt Up To 500 MHz

FIGURE 2231

I
SIZE A
H
G
F
ATTEN. E SCALE N/A

D 2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME.
3. DIMENSIONS ARE IN INCHES [mm].
C 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL.
B
A 022013

P/N CAD FILE

NOTES:

FIGURE 1 FIGURE 2 BNC FEMALE FSCM NO. 53919

DWG TITLE PE7008

BNC FEMALE

© 2013 Pasternack Enterprises All Rights Reserved PE7008-3 REV 3
