PE3C4136 CAD Drawing
Plenum N Male to 7/16 DIN Male Right Angle Low PIM
Cable Using SPP-250-LLPL Coax , LF Solder
7361
MALE
N SIZE A
6" FROM CABLE END 1 PLACE. 2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME. SCALE N/A
SERIAL # PIM LEVEL -zzzdBc 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL.
PIM LABEL - GREATER THAN 84" LABEL 2 PLACES NOTES: 3. DIMENSIONS ARE IN INCHES [mm]. 12/05/18 CAD FILE
LENGTH MEASURED FROM CONTACT TO END PE LABEL - LABEL CENTERED 84" OR LESS. 12" FROM CABLE END. PE3C4136 CAGE CODE 53919
www.PASTERNACK.com PART # DWG TITLE
SPP-250-LLPL
R
P.O. Box 16759 | Irvine | CA | 92623
THE ENGINEER'S RF SOURCE
Pasternack Enterprises, Inc.
HEAT SHRINK PROTECTOR (2X) Pasternack does not make Phone: (949) 261-1920 | Fax: (949) 261-7451 Website: www.pasternack.com | E-Mail: sales@pasternack.com
CONTACT 7/16 DIN MALE RA STANDARD TOLERANCES *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES -
.XXX ±0.005
.XX ±0.01
.X ±0.2
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.
PE3C4136 REV 1.2 6
