MCX Jack Connector Crimp/Solder Attachment
for RG188-DS, RG316-DS

RF Connectors
Technical Data Sheet PE4885

Configuration
• MCX Jack Connector • RG188-DS, RG316-DS Interface Type
• 50 Ohms • Crimp/Solder Attachment
• Straight Body Geometry
Applications
• General Purpose Test • Custom Cable Assemblies
.
Description
Pasternack’s PE4885 MCX jack connector with crimp/solder attachment for RG188-DS and RG316-DS is part of our full line
of RF components available for same-day shipping.
Our MCX jack connector PE4885 datasheet specifications and drawing with dimensions are shown below in this PDF.
Pasternack’s broad catalog of RF, microwave and millimeter wave connectors allows designers to configure and customize
their signal connections however they like. Whether the need is to provide an I/O for a board design, or simply create a custom
cable assembly configuration, Pasternack has the right connector for the job. Pasternack can also expertly build your custom
cable assemblies for you and ship same-day.

Mechanical Specifications
.
Weight 0.006 lbs [2.72 g]
.
Material Specifications
Description Material Plating
Body Brass Nickel
.

Environmental Specifications

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: MCX Jack Connector Crimp/Solder Attachment for RG188-DS, RG316-DS PE4885 -
Pasternack does not make
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.

PE4885 REV 1.1 1
