MHV Male Connector Crimp/Solder Attachment
for RG214, RG9, RG225, RG393

RF Connectors
Technical Data Sheet PE4350

Assembly Instruction 3. 2. CENTER CONDUCTOR OR BRAID. 1. ASSEMBLY PROCEDURES 3.8 22.9

.15

•
•
4.

.90

CRIMP SIZE REQUIRED
.40
10.2
CONTACT: SOLDER.

FERRULE: .429[10.90] HEX CRIMP TOOL.

FLARE BRAID AND INSERT THE BODY UNTIL IT SEATS.
STRIP CABLE TO THE DIMENSIONS SHOWN, DO NOT NICK
SLIDE FERRULE OVER BRAID AND CRIMP WITH CRIMP TOOL.
PUSH CENTER CONDUCTOR FULLY INTO CONTACT AND SOLDER.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: MHV Male Connector Crimp/Solder Attachment for RG214, RG9, RG225, RG393 PE4350 -
Pasternack does not make
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.
