Page 2341 - 1.0/2.3 to SHV RF Connector Datasheets

NOTICE OF PROPRIETARY RIGHTS THIS DOCUMENT CONTAINS CONFIDENTIAL DATA, INCLUDING TRADE SECRETS, PROPRIETARY TO TIMES SYM REVISION DESCRIPTION DFTM DATE APPD APPD
MICROWAVE SYSTEMS. DISCLOSURE OF THIS DATA IS EXPRESSLY CONDITIONED UPON YOUR ASSENT THAT ITS USE IS LIMITED TO USE WITHN A RELEASED FOR PRODUCTION Joslen 2017.08.11 TZ 2017.08.11
YOUR COMPANY ONLY. ANY OTHER USE IS STRICTLY PROHIBITED WITHOUT THE PRIOR WRITTEN CONSENT OF TIMES MICROWAVE SYSTEMS. A1 Change inner pin dimension Joslen 2017/12/01 TZ 2017/12/01

I. MATERIALS & FINISHES TC-240-NMH-X II. ELECTRICAL PROPERTIES
Components Materials Finishes Thk. (µ") Impedance (Ω): 50 Deburr
Body Brass Albaloy 80 Frequency Range (GHz): DC to 6 GHz
Center Cont. Brass Gold 50 Working Voltage (V): 2500
Ferrule Brass Albaloy 80 Insulation Resistance (MΩ): ≥10000
Nut Brass Albaloy 80 VSWR: ≤1.30 RECOMMENDED CABLE STRIPPING DIM'S
Insulator PTFE -- -- Insertion Loss(dB, f/GHz): -0.1x f Connector adds: 17.32 mm
Gaskt Silicone -- --
Shrink Tube (1/2"x1.5" 3:1)
III. ENVIRONMENT PROPERTIES IV. MECHANICAL PROPERTIES
According to Standard: IEC 61169-16
Temperature Range: -40°c~+125°c Center Cont.: Solder DFTM.
Thermal Shock: MIL-STD 202G, Meth.107, Cond.B Outer Cont.: Crimp MATL: UNLESS OTHERWISE SPECIFIED Joslen
Vibration: MIL-STD 202G, Meth.204, Cond.B Coupling Nut Torque (N.m): 1.7 ALL DIMENSIONS ARE IN mm DATE 2017/12/01 TIMES MICROWAVE SYSTEMS
Shock: MIL-STD 202G, Meth.213, Cond I Cbl-Connector Retention Force (N): 250 MACHINED SURFACES FINISH 1.6 RMS MAX. An Amphenol Company
Climatic Class: IEC 60068 55/155/56 Durability (cycles): 500 REMOVE ALL BURRS 0.15X45˚ MAX. BREAK CHKD KG TC-240-NMH-X
(2002/95/EC)RoHS: Compliant MACHINE CORNERS 0.15X45˚ D MAX. FILLET
R. TOLERANCES ON DECIMALS DATE 2017/12/01 Type N Male (Plug) Straight Solder
V. TOOLING USED ON: O .X ±0.3 .XX ±0.15 Pin No Braid Trim Connector for
Stripping Tool: 3192-152/CST-240A ANGLES ±2° FRACTIONS ± N/A APPD TZ LMR-240 Cable

Crimping Tool: 3190-667/CT-240/200/100 SCALE: DWG CODE DATE S R
N/A SIZE A4 DO NOT SCALE DRAWING IDENT 68999 2017/12/01 H T 1 OF 1 3190-6381 E V A1
