PE4088 CAD Drawing
TNC Male Connector Clamp/Solder Attachment for RG213, RG214,
RG8, RG9, RG11, RG225, RG393, RG144, RG215, RG216

2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME.
NUT 7361

SIZE A

GASKET

SCALE N/A

.75 19.0 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL.
WASHER CONTACT 07/09/18

.622 [15.80] ACROSS FLATS NOTES: 3. DIMENSIONS ARE IN INCHES [mm]. CAD FILE

BRAID CLAMP

1.50 38.1 CAGE CODE 53919
PE4088
BODY
TNC MALE DWG TITLE

7/16-28 UNEF R
