QMA Male to QMA Male Cable Assemblies

Check out our new RF calculators & conversion tools...

QMA Male to QMA Male Cable Using PE-C195 Coax

Product ID: PE38272
QMA Male to QMA Male Cable Using PE-C195 Coax

Image Views:  QMA Male to QMA Male Cable Using PE-C195 Coax high resolution
Zoom


Click for:PE38272 Datasheet
Please Enter Length to Calculate Price
Standard Lengths
12 in.24 in.36 in.48 in.60 in.72 in.
Custom Length
SHIPS SAME DAY
Length:
*Lengths are rounded up to the nearest quarter of inch or centimeter respectively. For precise lengths, please call
866-727-8376.
Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1QMA
Connector Gender 1Male
Connector Polarity 1Standard
Connector Angle 1Straight
Connector Mount Method 1None
Connector Impedance 150
Connector Series 2QMA
Connector Gender 2Male
Connector Polarity 2Standard
Connector Angle 2Straight
Connector Mount Method 2None
Connector Impedance 250
RF Cable Part NumberPE-C195
RF Cable TypePE-C195
RF Cable Impedance50


QMA Male to QMA Male Cable Using PE-C195 Coax

PE38272 is a QMA male to QMA male cable using PE-C195 coax. This Pasternack QMA male to QMA male cable assembly uses a 50 Ohm QMA for connector 1 and a 50 Ohm QMA for connector 2.

Our male QMA to male QMA cable assembly uses a flexible cable type that is 50 Ohm. Pasternack PE38272 QMA male to QMA male cable assembly is constructed with PE-C195 coax and the maximum VSWR is 1.33:1.
