SC Male Right Angle Connectors

Check out our new RF calculators & conversion tools...

SC Male Right Angle Connector Clamp/Solder Attachment for RG213, RG214, RG8, RG9, RG225, RG393, RG215

Product ID: PE4979
SC Male Right Angle Connector Clamp/Solder Attachment for RG213, RG214, RG8, RG9, RG225, RG393, RG215


Image Views:  SC Male Right Angle Connector Clamp/Solder Attachment for RG213, RG214, RG8, RG9, RG225, RG393, RG215 high resolution
Zoomalternate image
View 2


Click for:PE4979 Datasheet
Click for:PE4979 RoHS Cert
Click for:PE4979 REACH Cert
Available Quantity: 12
Pricing Table
QUANTITYPRICE
1-9$162.22
10-24$154.11
25-49$146.00
50+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
PolarityStandard
Connector SeriesSC
Connector GenderMale
Impedance50 Ohm
Body StyleRight Angle
Attachment MethodClamp/Solder
Mount MethodNone
Minimum FrequencyDC
Maximum Frequency11 GHz


SC Male Right Angle Connector Clamp/Solder Attachment for RG213, RG214, RG8, RG9, RG225, RG393, RG215

PE4979 SC male right angle coaxial connector has an interface type of RG213, RG214, RG8, RG9, RG225, RG393, RG215 and a 50 Ohm impedance. Pasternack SC male connector uses shield/contact clamp/solder as an attachment method. Our male SC right angle coaxial connector provides a minimum frequency of DC and a maximum frequency of 11 GHz.

The Pasternack right angle SC male coaxial connector has a ptfe dielectric type. The Pasternack SC coaxial connector has a brass body with nickel plating. Our PE4979 SCright angle connector uses brass contact. This SC male right angle coaxial RF connector is RoHS and REACH compliant.

This Pasternack right angle male SC connector will ship the same day as purchased. Our SC right angle male connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom SC connector cable assemblies that will ship the same day as well.
