SHV Jack Bulkhead Mount Connector Solder Attachment Solder Cup Terminal, .480 inch D Hole

Product ID: PE4499
SHV Jack Bulkhead Mount Connector Solder Attachment Solder Cup Terminal, .480 inch D Hole


Image Views:  SHV Jack Bulkhead Mount Connector Solder Attachment Solder Cup Terminal, .480 inch D Hole high resolution
Zoomalternate image
View 2


Click for:PE4499 Datasheet
Click for:PE4499 RoHS Cert
Click for:PE4499 REACH Cert
Available Quantity: 4,047
Pricing Table
QUANTITYPRICE
1-24$24.73
25-49$23.00
50-99$21.27
100-249$19.78
250+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
PolarityStandard
Connector SeriesSHV
Connector GenderJack
Impedance50 Ohm
Body StyleStraight
Attachment MethodSolder
Mount MethodBulkhead
Minimum FrequencyDC
Maximum Frequency300 MHz


SHV Jack Bulkhead Connector Solder Attachment Solder Cup Terminal, .480 inch D Hole

PE4499 SHV jack bulkhead terminal connector has an interface type of solder cup and a 50 Ohm impedance. Pasternack SHV jack bulkhead connector uses shield/contact solder as an attachment method. Our jack SHV terminal connector provides a minimum frequency of DC and a maximum frequency of 300 MHz.

The Pasternack SHV jack bulkhead terminal connector has a teflon dielectric type and a VSWR of 1.3. The Pasternack SHV terminal connector has a brass body with nickel plating. Our PE4499 SHV connector uses brass contact. This SHV jack bulkhead terminal RF connector is RoHS and REACH compliant.

This Pasternack jack SHV bulkhead connector will ship the same day as purchased. Our bulkhead SHV jack connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom SHV connector cable assemblies that will ship the same day as well.
