SHV Jack Straight Connectors

Check out our new RF calculators & conversion tools...

SHV Jack Bulkhead Mount Hermetically Sealed Connector Solder Attachment Solder Cup Terminal, .350 inch D Hole

Product ID: PE4500
SHV Jack Bulkhead Mount Hermetically Sealed Connector Solder Attachment Solder Cup Terminal, .350 inch D Hole


Image Views:  SHV Jack Bulkhead Mount Hermetically Sealed Connector Solder Attachment Solder Cup Terminal, .350 inch D Hole high resolution
Zoomalternate image
View 2


Click for:PE4500 Datasheet
Click for:PE4500 RoHS Cert
Click for:PE4500 REACH Cert
Available Quantity: 242
Pricing Table
QUANTITYPRICE
1-24$62.99
25-49$59.84
50-99$56.69
100-249$54.17
250+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
PolarityStandard
Connector SeriesSHV
Connector GenderJack
Impedance50 Ohm
Body StyleStraight
Attachment MethodSolder
Mount MethodBulkhead


SHV Jack Bulkhead Hermetically Sealed Connector Solder Attachment Solder Cup Terminal, .350 inch D Hole

PE4500 SHV jack bulkhead hermetically sealed terminal connector has an interface type of solder cup and a 50 Ohm impedance. Pasternack SHV jack bulkhead connector uses shield/contact solder as an attachment method.

The Pasternack SHV jack bulkhead hermetically sealed terminal connector has a ptfe dielectric type. The Pasternack SHV terminal connector has a brass body with nickel plating. This SHV jack bulkhead hermetically sealed terminal RF connector is RoHS and REACH compliant.

This Pasternack jack SHV bulkhead connector will ship the same day as purchased. Our bulkhead SHV jack connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom SHV connector cable assemblies that will ship the same day as well.
