SMA Male QD Connector Crimp/Solder Attachment For RG142, RG223, RG400, RG55

Product ID: PE44461

Pricing

QuantityPrice
1-24$67.13
25-49$64.44
50-99$62.43
100-249$61.09
250+Call Us

* All Prices are in US Dollars and do not include duties

Buy

Available Quantity: 157
Shipping Truck
Same-Day Shipping!
Order in the next hours!
* All Prices are in US Dollars and do not include duties

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
PolarityStandard
Connector SeriesSMA
Connector GenderMale
Impedance50 Ohm
Body StyleStraight
Attachment MethodCrimp/Solder
Mount MethodNone
Minimum FrequencyDC
Maximum Frequency12.4 GHz
Interface Type 1RG142
Interface Type 2RG223
Interface Type 3RG400
Interface Type 4RG55

Description

SMA Male QD Connector Crimp/Solder Attachment For RG142, RG223, RG400, RG55

PE44461 SMA male coaxial qd connector has an interface type of RG142, RG223, RG400, RG55 and a 50 Ohm impedance. Pasternack SMA male connector uses shield/contact crimp/solder as an attachment method. Our male SMA coaxial connector provides a minimum frequency of DC and a maximum frequency of 12.4 GHz.

The Pasternack SMA male coaxial qd connector has a teflon dielectric type and a VSWR of 1.27. The Pasternack SMA coaxial connector has a brass body with gold plating. Our PE44461 SMA connector uses beryllium copper contact. This SMA male coaxial qd RF connector is REACH compliant.

This Pasternack male SMA connector will ship the same day as purchased. Our SMA male connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom SMA connector cable assemblies that will ship the same day as well.
